4000 Lift

Metal Craft Boat Lift Model 4000 is available in two series; Model 4000-110 and Model 4000-122.  The difference between the two models is the beam width.

Metal Craft Boat Lifts are made entirely of quality aluminum structural components, aircraft grade stainless steel cables and corrosive resistant zinc coated fasteners. All bunks and side guides are made from pressure treated lumber and covered with marine grade carpet, which are easily replaced versus plastic bunk models.  Boat lift bunks are available in three options: Standard (included in the base price of the lift), Deluxe and Pontoon.  The upgraded, optional deluxe side guides feature an “L” shape, which provides room for boaters to stand while entering and exiting the watercraft. The Lorenz 42” black powder coated, 14 gauge steel winch wheel is standard on all models.  The Boat Lift Boss electric winch is available as an upgrade along with a variety of closed and open-ended canopies available in Sunbrella Fabric, CoverTuff Vinyl or Harbor Time Fabric.

Metal Craft Boat Lifts have a 15 year Limited Warranty on the aluminum components and welds.

Features & Benefits

Model 4000-110

  • Beam Width, Maximum: 110 inches
  • Lifting capacity: 4000 lbs.
  • Lift Height: 66 inches
  • Minimum Water Depth to Cover Cradle: 8″
  • Weight: 454 lbs.; Size: 121″ W x 125″ L

Model 4000-122

  • Beam Width, Maximum: 122 inches
  • Lifting capacity: 4000 lbs.
  • Lift Height: 66 inches
  • Minimum Water Depth to Cover Cradle: 8″
  • Weight: 465 lbs.; Size: 133″ W x 125″ L
4000 Lift

Aircraft-grade Stainless Steel

Metal Craft Boat Lifts are made entirely of quality aluminum structural components, aircraft-grade stainless steel cables and corrosive resistant zinc coated fasteners.

3 Lift Bunk Options

Boat lift bunks are available in three options: Standard (included in the base price of the lift), Deluxe, and Pontoon.

Marine-grade

All bunks and side guides are made from pressure-treated lumber and covered with marine-grade carpet, which is easily replaced versus plastic bunk models.
